Details

---

Model :


• TON-XF5771

---

Technical Parameter :


Locking efficiency:	0.8-1.5s/screw
Locking range:	600 × 400 × 100 (L × W × H)
Control system:	CCD control system
Guide rail:	HIWIN (Taiwan)
Transmission method:	HIWIN double slide rail + HIWIN lead screw
Positioning accuracy:	± 0.01-0.02mm
Traverse speed:	X-axis : 800mm/s, Y-axis: 800mm/s, Z-axis: 500mm/s
Axis travel:	X-axis : 600mm, Y-axis: 400mm, Z-axis: 100mm
Feeding method:	Air-blown type
Electric screwdriver:	Intelligent electric screwdriver/Qilisu/Japan HIOS/Servo electric screwdriver
Feeder:	Quanfeng
Program capacity:	99+
Communication port:	USB
Dimensions:	850 × 693 × 750 (L × W × H)
Weight:	70 kg
Maximum load:	10 kg
Air supply:	0.3-0.8 MPa
Power supply:	AC220V
Rated power:	1500W

---
