Details
Model :
- TON-G200
Technical Parameter :
| Mixing ratio: | 1:1-10:1 (depending on user's adhesive configuration) |
| Dispensing speed: | 0.6-10g/1S; 1.5-20g/1S optional (varies depending on adhesive characteristics) |
| Dispensing accuracy: | Glue volume ±1%, ratio: ±1% |
| Head sealing pressure: | MAX≤ 3 Mpa |
| Applicable viscosity: | Within 20000 CPS |
| Operation mode: | Automatic + Manual |
| Glue volume ratio control: | High-precision metering pump + motor |
| Flow rate counting: | Visual |
| Programming method: | Teach-in programming software |
| Electrical control system: | PLC + industrial touch screen (program setting, modification, storage, etc.) |
| Adhesive cut-off system: | A and B adhesive separation instantaneous automatic back suction system |
| Adhesive mixing system: | High-speed brushless dynamic stirring device |
| Adhesive stirring system: | Fixed-speed motor stirring |
| Glue tank capacity: | A tank: 30L, B tank: 30L, Cleaning tank: 2L |
| Equipment weight: | 300KG |
| Equipment Specifications: | Length: 1350MM, Width: 80MM, Height: 1750MM |
| Air Supply: | 0.4-0.8 Mpa |
| Power Supply: | AC220V |
| Rated Power: | 800W |
