Details
Features :
- Dual feed pumps ensure continuous material supply.
- Resistance level gauge monitors material usage.
- Vacuum suction cup ensures no air bubbles mix into the glue during changes.
- Automatic pressure switching during material changes and normal production.
- Rotor and stator are made of high-quality materials with excellent wear resistance and corrosion resistance.
Applications :
- Applicable glue container packaging: 5-gallon containers
- Compatible glue types: Single-component or two-component glues
- Suitable for glue characteristics: High-filler formulations
- Designed for glue viscosity: High-viscosity glues
Technical Parameters :
| Equipment dimensions (unit: mm) | 700mm × 800mm × 820mm |
| Weight | 200kg |
| Air supply | 0.45-0.75MPa |
| Powered by | AC220V, 50HZ |
| Inner diameter | 280mm |
| Maximum height | 400mm |
| Amount of glue supplied per transfer | 10cc |
| Rotor material | Zirconia ceramic |
| Stator material | Polyurethane wear-resistant |
| Outer diameter | 295mm |
