Details
Features :
- Multi-stage heating and PEAK heat insulation plate reduce heat loss and ensure optimal hot-melt effect.
- High-precision volume control, suitable for various viscosities, meeting the needs of micro-volume and multi-material dispensing.
- Advanced DC servo motor drive system provides stable power and ensures precise control of dispensing volume.
- Stator, rotor, and wetted parts are made of corrosion-resistant and high-temperature-resistant materials, adaptable to a wide range of working environments.
- Lightweight design reduces equipment weight, facilitating operation and installation.
Applications :
- Suitable for small to medium dispensing, coating, and potting tasks
- Ideal for applying silicone seals and thermal paste
- Works with medium- to high-viscosity materials
- Compatible with silicone, epoxy resin, and thermal conductive grease
Technical Paremters :
| Minimum dispensing amount | 0.01ml |
| Applicable viscosity (CPS) | 0-500,000cps |
| Motor | DC servo |
| Reducer | 103 |
| Motor speed (rpm) | 10,000 RPM |
| Accuracy | +0.0002ml |
| Stator material | Corrosion-resistant and high-temperature resistant composite materials |
| input pressure | 0-6kgf/cm2 |
| Output pressure | 25kgf/cm2 |
| Wetted part material | SUS304/FFKM |
| Use temperature | 90-200°C |
| Weight | 3kg |
| Dispensing consistency | >99% |
| Rotor material | 304 |
