Details

---

Model :

• CPM1A-20CDR-A-V1

---

Applications :




---

Specification :


Type	Parameter
Mount	Chassis Mount, DIN Rail, Screw
Mounting Type	Chassis Mount, DIN Rail
Package / Case	100
Weight	1.1lbs 499g
Number of I/Os	20
Operating Temperature	0°C~55°C
Series	CPM1A
Published	2004
Part Status	Obsolete
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Screw
Max Operating Temperature	55°C
Min Operating Temperature	0°C
Voltage - Supply	100V~240VAC
Depth	50mm
Number of Outputs	8
Approval Agency	CE, CSA, Lloyd, NK, UL
Memory Size	1KWords
Number of Inputs	12
Display Type	No Display
Communications	RS-232C
Number of Inputs and Type	12 - Digital
Number of Outputs and Type	8 - Relay
Expandable	Non-Expandable
Software	CX-One
Length	90mm
Width	86mm
RoHS Status	RoHS Compliant

---
