Double Station Separator Machine VIPIN-M3045DT
Model : VIPIN-M3045DT
(1).png)
Specification :
| Model | VIPIN-M3045DT |
| Effective cutting size | 350*400mm |
| cutting function | Straight line, L-shape, U-shape, Circle, Arc, Abnormity, etc |
| worktable | Double work table |
| Machine repeat accuracy | +0.01mm |
| Cutting accuracy | +0.02mm |
| Max movement speed | XY : 1000 mm / s, Z : 800 mm / s |
| Max movement range | X:750 Y:500 Z: 100mm X:750 Y:650 Z: 100mm |
| Spinlde speed | Max : 40000—60000rpm |
| Milling tooling changing method | Manual/automatic tool change |
| Cutting speed | 0~100 mm / s |
| Tool fail detection | Yes / No / Optional |
| Operation interface | Windows 7/10 |
| Control mode | Computer control system |
| XYZ axis drive | Ac servo system |
| Applicable milling cutter size | Diameter : 0.5 — 3.0mm |
| Power specifications | AC 220~240V / 415V / 50Hz / 60Hz 2Kw |
| Machine size | 1200(W)*1050(D)* 1450(H) |
